TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger

TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger

  • TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger
  • TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger
TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger
Product Details:
Place of Origin: china
Brand Name: Real TIG ,NB TIG
Certification: ISO
Model Number: 208-5236
Payment & Shipping Terms:
Minimum Order Quantity: 2 tons
Price: USD1.2-1.5 USD/Kg FOB Ningbo
Packaging Details: standard wooden case 1050*710*840
Delivery Time: 30-35days
Payment Terms: T/T, L/C
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Material: Alloy Steel Hardness: 46-48HRC
Impact Value: 15J Color: Yellow /black
High Light:

2713-1236RC Excavator Bucket Teeth

,

Daewoo Rock Bucket Teeth

,

Digger Rock Bucket Teeth

NB TIG® 2713-1236RC Daewoo/Doosan SOLAR rock bucket tooth for DH450 DH470 Doosan-Daewoo SOLAE styleDigger teeth and adapter

Wear Parts and G.E.T. for Heavy Equipment parts dealer/distributor.



Part number:

TOOTH :2713-1236RC 16.7KGS

ADAPTER :2713-1273

Pin:
2705-1034
2114-1931





TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger 0TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger 1

Color may vary



other Doosan-Daewoo style tooth point



P/N TYPE U/W KG Model
2713-1221 STANDARD TIP 3.7 DH130
2713Y1217/DY220S 4.6 DH220/170
2713Y1217/DY221S-2 5
2713Y1217/27131217 5.8
2713Y1217/DH220S 5.7
2713Y1217/HD220-1 6.45
2713Y1219-2 7 DH280/320
2713Y1219 7.4 DH280/320
2713Y0032-2 9.2 DH360
2713Y0032 9.5 DH361
18S ROCK STYLE   DH55/XD60
2713Y1221RC-L 3.8 DH130
2713Y1217RC 6 DH220/170
DH220RC 6.6
2713Y1217RC-2 5.4
2713Y1217RCK 5.9
2713Y1219RC 6.5 DH280/320
2713Y1219RC-2 6.2 DH300
2713Y0032RC 10.3 DH360
2713Y0032RC-2 8.8 DH360
2713Y1236RC 16.8 DH420
2713-1236TL SHARP CENTER 16.2 DH420
2713Y6052BC-L SIDE CUTTER 2.1 DH55/XD60
2713Y6052BC-R 2.1
2713-1059/DY220BC 16.5 DH220/170
2713-1050/DY220BC 16.5
2713-1047/DY280BC 17.8 DH280/EX300
2713-1048/DY280BC 17.8
2713Y1240 22 DH420
2713Y1241 22
18Z ADAPTER   DH55/XD60
2713-1222 5.9 DH130(36)
27131218 8.75 DH220(38)
2713Y1218-4 9.4 DH220(41)
DH220Z 8.9 DH220(40)
2713Y1220 11 DH300(50)
2713Y1220-2 11 DH300(41)
DY300Z 12.8 DH300(41)
2713Y0033 17.9 DH360(56)
KP9005354 24.5 DH420
Bofors bucket teeth and adapter
P/N TYPE U/W KG
4046729 TIP 7
4046663 11.3
3027689/38104 14.5
4046818/38104 2.5
4046799/31104 3.5
3032682/32105 7.5
4046816/31006 1.2
4046797/31004 2
4046819/32004 4
4046862/33004 5.3
4044339/34004 8.5
3031387/35003 16.4



TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger 2



OTHER FLASH MOULDED ADAPTER FOR CHOOSE

4T1204 WELD ON ADAPTOR 2.05 J200
1U1254 5.3 J250
1U1304 7.6 J300
1U1354 15 J350




much more Cat teeth

Cat TEETH AND ADAPTERS
P/N TYPE U/W KG Model
1U3201 SHORT 1.45 J200
6Y6221 2 J225
1U3251 2.7 J250
1U3301 4 J300
1U3351 5.5 J350
7T3401 8.2 J400
9W8451 11.5 J450/460
9W8551 15.5 J550
6I6601   J600
1U3202 LONG TOOTH 1.35 J200
6Y3222 2.2 J225
1U3252 2.9 J250
1U3302 4.3/4.7 J300
1U3352 5.8/6.0 J350
7T3402 8.9/9.5/10.6 J400
9W8452/ 1U3452 12.4/12.65 J450
9W8552 /1U3552 19.5 J550
6I6602 34 J600
1U3202P ROCK CHISEL 1.35 J200
6Y3222RC 2.8 J225
1U3252RC 3.5 J250
1U3302RC-L 4.95 J300
1U3352RC-2 7 J350
7T3402RC / 7T3402RC-2 9.5/9.88 J400
9W8452RC/ 1U3452RC-3 13.4 J450
9W8552RC 24 J550
6I6602RC 39 J600
1U3352RCH / 1U3352RC HEAVY DUTY PENETRATION 8.2 J350
9W8452RCH / 1U3452RC 15 J450/460
8E4222 HEAVY DUTY LONG TOOTH 3.1 J220
9N4252 4.2 J250
9N4302 5.5 J300
9N4352 8.6 J350
8E4402 11.5 J400
9N4452 17.5 J450
9N4552   26 J550
1U3209 PENETRATION 1.2 J200
6Y8229 2 J225
9J4259 2.5 J250
9J4309 3.6 J300
9J4359 5.5 J350
6Y7409 8.8 J400
9W8459 9.7 J450/460
9W8559 15.5 J550
135-9300/4T2303RP RP 9 J300
144-1358/4T2353RP 10 J350
135-9400/7T3403RP 17 J400
138-6459/W1453RP 23 J450/460
138-6552/9W1553RP 29 J550
4T2203/9J4203 HEAVY DUTY ABRASION 1.8 J200
4T2253 3.5 J250
4T2303 5.3 J300
4T2353 7.3 J350
9W1453 14 J450/460
9N4253 HEAVY DUTY ABRASION 4.55 J250
9N4303 7.2 J300
9N4353 11 J350
7T3403 13.5 J400
9N4453 21.4 J450/460
6Y2553 31 J550

TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger 3




·A comprehensive range is available to suit:

Cat Komatsu ,  Daewoo , ,Hensley,Hitachi, H & L,Hyundai,· Volvo

· JCB.· Bofors· John Deere· Case· Kobelco· Liebherr

· Bobcat

Casting is a manufacturing process by which a liquid material is usually poured into a mold, which contains a hollow cavity of the desired shape, and then allowed to solidify. The solidified part is also known as a casting, which is ejected or broken out of the mold to complete the process. We use the precision casting /lost wax casting to product our bucket teeth

Casting Bucket Teeth
Material 1# Hardness :48-52HRC Impact Value :>15J
Material 2# Hardness :48-52HRC Impact Value :>20J



welcome for quotation !

TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger 4TIG 2713-1236RC Daewoo / Doosan Solar Rock Bucket Teeth For DH450 DH470 Digger 5
